| JM Rubber Mount |
 |
| |
| Feature |
| |
|
 |
Multiple-layer configurations. |
|
Wide-range load with low constant natural frequency. |
|
Easy, low cost installation. |
|
Excellent stability. |
|
Excellent reliability due to rugged and simple construction. |
|
Noise attenuation. |
| |
|
|
|
|
| |
| |
| Dimensions/Rated Capacity |
| |
| Part Number |
Load
Kgs |
Rated
Capacity(Kgs) |
Compression
(mm) |
frequency
(Hz) |
Dimensions(mm) |
| Min |
Max |
Dφ |
H |
A |
B |
φCS |
φBD |
| JM-0502-C.P. |
30 |
15 |
35 |
5.0 |
7.0 |
50 |
30 |
91 |
73 |
M8 |
9 |
| JM-0503-C.P. |
30 |
15 |
35 |
7.0 |
6.0 |
50 |
44 |
91 |
73 |
M8 |
9 |
| JM-0602-C.P. |
60 |
30 |
80 |
9.0 |
7.0 |
60 |
35 |
105 |
83 |
M8 |
11 |
| JM-0603-C.P. |
60 |
30 |
80 |
13.0 |
6.0 |
60 |
51 |
105 |
83 |
M8 |
11 |
| JM-0802-C.P. |
120 |
60 |
150 |
11.0 |
6.3 |
80 |
47 |
140 |
110 |
M10 |
13 |
| JM-0803-C.P. |
120 |
60 |
150 |
15.0 |
5.3 |
80 |
68 |
140 |
110 |
M10 |
13 |
| JM-1202-C.P. |
250 |
120 |
300 |
18.0 |
5.0 |
120 |
67 |
210 |
165 |
M12 |
15 |
| JM-1203-C.P. |
250 |
120 |
300 |
27.0 |
4.2 |
120 |
98 |
210 |
165 |
M12 |
15 |
| JM-1602-C.P. |
550 |
280 |
700 |
25.0 |
4.4 |
160 |
86 |
280 |
220 |
M16 |
19 |
| JM-1603-C.P. |
550 |
280 |
700 |
39.0 |
3.5 |
160 |
126 |
280 |
220 |
M16 |
19 |
|
| |
