JRN Rubber Mount JRN產品圖

Feature

Superior safety.
Weather resistant finish.
Heavy-duty vibration isolation.



Applicaions JRN尺寸圖

Motors、Engine、Generators
Transformer
Electronic facilities 、On-board equipment


JRN型橡膠式避震器目錄下載 JRN型橡膠式避震器目錄下載處

JRN型橡膠式避震器安裝說明下載 JRN型橡膠式避震器安裝說明下載處



   Dimensions/Rated Capacity

Part Number A B C D E F H CS Rated
Defl.
Hardness Spring
Rate
Load
Range
mm mm mm mm mm mm mm   mm Shore A Kg/mm Kgs
JRN-500 186 150 96 125 19.5 13.5 43 M16 5 55 118 450~750
JRN-1000 186 150 96 125 19.5 13.5 43 M16 5 65 213 800~1000
